The Ford 5R55S: Engineering Evolution and Modern Solutions

The 5R55S transmission marked Ford's significant advancement into sophisticated electronic control for their rear-wheel-drive platforms. Introduced in the early 2000s for vehicles like the Ford Explorer, Mercury Mountaineer, Lincoln LS, and Ford Thunderbird, this five-speed automatic transmission brought refined shift control and overdrive efficiency to Ford's mid-size SUV and luxury car segments. Building upon its predecessor, the 5R55W, this transmission incorporated enhanced electronic control, updated solenoid design, and modified valve body architecture.

One of the most critical issues we address at Bench Built Transmissions is the notorious servo bore wear in the case. Our proprietary repair process involves precision boring of the worn servo bores and installing custom-machined aluminum sleeves. This restoration process not only repairs the wear but actually strengthens the case beyond its original specifications, preventing future servo-related failures. This attention to detail in case preparation sets the foundation for a reliable rebuild.

The 5R55S faces several common challenges that our rebuilds specifically address. Solenoid reliability issues often manifest as delayed engagement, erratic shifting, and inconsistent pressure control. Our solution includes installing updated solenoid packs with enhanced durability and more precise pressure control characteristics. Mechanical concerns such as input shaft wear, planetary gear set durability, and drum bearing failures are addressed through improved metallurgy and design modifications.

Electronic integration plays a crucial role in these transmissions. We've developed specific protocols for addressing solenoid pack failures, sensor malfunctions, and computer communication issues. Each rebuild receives a comprehensive electronic diagnostic evaluation, ensuring proper communication between the transmission and vehicle computer systems. Our valve body modifications improve hydraulic control while maintaining proper electronic feedback.

The rebuild process at Bench Built Transmissions goes beyond simple parts replacement. After the case receives our servo bore sleeve upgrade, we perform a complete disassembly and inspection. Every unit receives our modified valve body calibration, enhanced servo application, and updated friction materials. We've developed specific modifications to improve lubrication paths, addressing one of the original design's weaknesses. These improvements, combined with superior sealing technology and enhanced cooling provisions, result in a transmission that significantly outperforms the original.
